J Cancer 2025; 16(1):171-182. doi:10.7150/jca.99944 This issue Cite

Research Paper

Impact of ALDH1A1 Expression in Intrahepatic Cholangiocellular Carcinoma

Konrad Kurowski^1,2, Melanie Föll¹, Tilman Werner^1,3,4, Oliver Schilling^1,6, Martin Werner^1,2,5,6, Stefan Fichtner-Feigl^6,7, Bertram Bengsch⁸, Peter Bronsert^1,2, Philipp Anton Holzner^7*, Sylvia Timme^1,2*

1. Institute for Surgical Pathology, Medical Center - University of Freiburg, Faculty of Medicine, University of Freiburg, Germany.
2. Core Facility Histopathology and Digital Pathology Freiburg, Medical Center - University of Freiburg, Germany.
3. Faculty of Biology, University of Freiburg, Germany.
4. Spemann Graduate School for Biology and Medicine (SGBM), Freiburg, Germany.
5. Tumorbank Comprehensive Cancer Center Freiburg, Medical Center - University of Freiburg, Germany.
6. German Cancer Consortium (DKTK) and German Cancer Research Center (DKFZ), Heidelberg, Germany.
7. Department of General and Visceral Surgery, Medical Center - University of Freiburg, Faculty of Medicine, University of Freiburg, Germany.
8. Faculty of Medicine, Clinic for Internal Medicine II, Gastroenterology, Hepatology, Endocrinology, and Infectious Disease, University Medical Center Freiburg, Freiburg, Germany.
*Equal contributions to this work.

✉ Corresponding author: Dr. Sylvia Timme, Institute for Surgical Pathology, University Medical Center Freiburg, Breisacher Straße 115A, 79106 Freiburg, Germany. Tel.: +49(0)761-270-80060; E-mail: sylvia.timmede.

Abstract

Background: Intrahepatic cholangiocarcinoma (iCC) is a rare malignant liver tumor with limited therapeutic advancements. Despite its increasing global incidence knowledge of treatment options remains stagnant, leading to poor five-year patient survival rates and high recurrence post-surgery. ALDH1A1, a member of the ALDH superfamily, is associated with cancer stem cells and has conflicting reports regarding its prognostic role in iCC.

This retrospective study analyzed 69 iCC patient samples from University Hospital Freiburg. Tissue microarrays (TMAs) were constructed, and ALDH1A1 expression was immunohistochemically assessed using machine learning algorithms. Script-based Survival analysis employed Kaplan-Meier curves, log-rank tests, and Cox Proportional Hazards Models.

ALDH1A1 overexpression, both in tumor and stromal cells, correlates with favorable overall survival in iCC. Gender-specific analyses indicate a more pronounced effect in females. These findings suggest ALDH1A1 as a potential prognostic biomarker in iCC, warranting further validation in larger cohorts and exploration as a therapeutic target.

Introduction

Intrahepatic cholangiocarcinoma (iCC) is the second most common primary malignant tumor of the liver after hepatocellular carcinoma (HCC). Overall, representing about 15% of all primary liver tumors, iCC is a rare tumor entity, accounting for only 3% of all malignant gastrointestinal tumors (1,2). Nevertheless, the incidence of iCCs is increasing worldwide, but interestingly, knowledge about therapeutic treatment options is almost standing still. This might be attributed to the relatively limited foundational knowledge of iCC in comparison to other entities. The stagnation of knowledge is best reflected by the dismal five-year patient overall survival of up to of 20% and the high recurrence rates after surgical resection (3-5).

Intrahepatic cholangiocarcinoma derives from the interlobular bile ducts (6). Considering the histopathological growth pattern, iCCs form tumor masses, are periductal-infiltrating, or intraductal-growing (1,7).

Risk factors for iCC comprise hepatitis B/C infection, parasitic liver infections, liver cirrhosis, cholestasis, diabetes mellitus type II, obesity, alcohol consumption, smoking, asbestosis, and exposure to organic solvents (8-10).

The aldehyde dehydrogenase (ALDH) superfamily comprises a nicotinamide-adenine dinucleotide phosphate-positive (NAD-P+) dependent enzyme. ALDH catalyzes the oxidation of aldehydes to their corresponding carboxylic acids and converts retinol into retinoic acid (11). Subcellularly, ALDH is predominantly found within the cytosol but can also be detected within the mitochondria, the endoplasmic reticulum, and / or the nucleus (12).

Within the ALDH superfamily, ALDH1A1 has been described as a marker for cancer stem cells (CSCs), first reported by Ginestier et al. (13). Ginestier et al. demonstrated that in breast cancer elevated ALDH1 levels correlated with poor patient overall survival and an increased tumor-initiating ability in vivo. Subsequent studies not only supported the findings of Ginestier et al. (14-17) but also depicted biologically relevant ALDH1A1-triggered mechanisms such as tumor growth, drug - (18-20) and irradiation resistance (21,22).

Nevertheless, more and more publications indicate a protective biological function of ALDH1A1 within the tumor, as well as within the surrounding tumor stroma (23-28).

Considering iCC, only a few publications have analyzed the prognostic impact of ALDH1A1 expression. Hereby, the overexpression of ALDH1A1 has been controversially described as a dismal (18), good (29) and non-relevant (30) prognosticator.

Materials and Methods

Human tissue samples

The presented study included 69 chemonaive patients who underwent primary resection for intrahepatic cholangiocarcinoma at University Hospital Freiburg from 2000 to 2014. The study received approval from the local ethics committee of the Faculty of Medicine at the Albert-Ludwigs-Universität Freiburg (REF 21-1684).

All tissue specimens were processed for tumor diagnostics, involving standardized sectioning, 24-hour formalin fixation, paraffin embedding, cutting, hematoxylin-eosin staining, and review by experienced pathologists. After diagnosis, all slides were stored at the Institute for Surgical Pathology (ISP), University Center Freiburg, Germany. Diagnostic archive tissue specimens and corresponding slides were retrieved from the ISP archive and re-reviewed according to current UICC and WHO classifications. Next, all tissue specimens and corresponding clinicopathological data were pseudonymized. Clinicopathological data included TNM classification, WHO classification, R-status, gender, age at iCC onset, and patients' overall survival.

TMA construction

Digitized pseudonymized H&E slides (PANNORAMIC® 1000-Scanner, Sysmex) were uploaded to a local server (Casecenter, Sysmex, Service Unit v. 2.0903111521). For each patient, three circular tumor regions of interest (ROIs), each 1.0 mm in diameter were annotated using the Caseviewer software (Sysmex, v. 2.3) by experienced pathologists. The tissue microarrays (TMAs) were constructed with the TMA Grand Master (Sysmex). After loading the microarrayer with donor and acceptor blocks, the TMA Grand Master identified each block's barcode labeling according to its annotated block pseudonym. The TMA Grand Master accessed the local server and matched the previously annotated and uploaded digital slides with the corresponding donor block. All slides were aligned with the photographed donor blocks and reviewed for accurate consistency. Next, annotated ROIs were transferred to the acceptor block. Considering TMA design, an asymmetric array for simple TMA orientation with 11 columns and 17 rows was chosen. To avoid corrupting batch effects, the acceptor TMA arrays were designed and transferred in a random fashion. Additionally, each TMA received on-slide control cores (placenta and tonsil, three each per TMA acceptor block).

After the transfer process's completion, the acceptor block was placed on top of a glass slide, heated to 37 °C for 60 minutes, and immediately cooled down on crushed ice for 10 minutes. This procedure was repeated twice.

Immunohistochemistry

Immunohistochemical staining was performed with a commercially available primary antibody for Human Aldehyde Dehydrogenase 1-A1 (ALDH1A1; R&D Systems, mouse monoclonal Mouse IgG2B Clone # 703410 [MAB5869]) and the EnVision FLEX detection system (Dako, K8000). Tissue sections of 2µm thickness were cut (Leica RM2255 rotary microtome) and deparaffinized in the ISP. The staining protocol included the following steps: incubation with blocking reagent (EnVision FLEX Peroxidase Blocking Reagent, DAKO) for 10 minutes, ALDH1A1 staining with the afore mentioned primary antibody at a concentration of 2,5µg/ml (1/200), with mouse linker (EnVision Flex + Mouse Linker, DAKO) for 15 minutes, with horseradish peroxidase (EnVision FLEX/HRP, DAKO) for 20 minutes, with Envision FLEX DAB + Substrat Buffer (1:51) for 10 minutes and finally counterstained in hematoxylin.

As positive control peripheral nerve bundles (in prostate specimen), known for its consistent expression of ALDH1A1 (31), were used (Figure 1). The surrounding prostatic glands served as internal negative control (32). Furthermore omission of the primary antibody was conducted for negative control.

 Figure 1

Prostate specimens were used for validating the ALDH1A1 antibody. The perinueral sheaths served as positive controls whereas the prostatic glands served as internal negative controls.

Tissue microarray analysis

For digital image analysis, the immunohistochemically stained TMA slides were digitized (MIRAX) and imported into the open-source freeware QuPath (v. 0.3.0) (33). After applying the TMA dearrayer to identify tissue cores ("TMA core diameter": 1.2 mm, "Column labels": X1-X11, "Row labels": Y1-Y17, "Label Order": Row first, "Density threshold": 4, "Bound scale factor": 105), the TMA grid was adjusted. Missing cores or cores with prominent artifacts were discarded; inaccurately aligned core annotations were adjusted. A TMA map with patient identifiers was imported to enable correlation with clinical data. For proper stain separation, automated color deconvolution was applied on a representative region including strong hematoxylin and DAB staining, as well as an area of background.

Cells were detected and their cytoplasmic immunohistochemical staining was evaluated using the “Positive cell detection command” (“Detection image: Hematoxylin OD”, “Requested pixel size: 0.5 µm”, “Background radius: 0.0µm”, “Median filter radius: 0.0 µm”, “Sigma: 1.0 µm”, “Minimum area: 15.0 µm²”, “Maximum Area: 350.0 µm²”, “Threshold: 0.2”, “Max background intensity: 0.0”, “Split by shape: true”, “Exclude DAB (membrane staining): false”, “Cell Expansion: 5.0 µm”, “Include cell nucleus: true”, “Smooth boundaries: true”, “Make measurements: true”, “Threshold compartment: Cytoplasm: DAB OD mean”, “Threshold 1+: 0.075”, “Threshold 2+: 0.15”, “Threshold 3+: 0.35”, “Single threshold: false”).

For tissue classification a total of 8570 cells with a cumulative area of 1.2 mm² were annotated as tumor, stroma, and “other” cells (e.g., immune-cell infiltrates, necrotic cells) separately (“Classify” > “Object classifier” > “Train object classifier”) throughout various TMA cores, incorporating all TMA slides. These manually classified cells served as training data for the classification model using the Random Tree machine learning algorithm. The model was trained on the extracted features of the training data to capture the patterns and relationships between these features and the target classes. The model evaluated the similarity of each cell's features with the known features of the training data and assigned them to the corresponding classes. The classifier was applied across all TMA cores. The resulting cell classification was visually evaluated by a pathologist on all cores for its discriminatory power and reliability in the assignment of tissue classes. Based on the review of the results, adjustments were made to improve performance by annotating misclassified cells. Through iterative adjustment and review, the cell classification model was continuously optimized (Figure 2). The resulting cell classification and staining intensity were re- examined and reviewed by pathologists for data consistency. The derived data for tumor and stroma cells of each core, including their respective patient identifiers, were then exported as a text file for further statistical analysis.

 Figure 2

Three cores of iCC with high, low and no expression of ALDH1A1 in the tumor cells. The intensity of expression was color-coded in QuPath (red = 3+, orange = 2+, yellow = 1+, blue 0).

Statistical analysis

All statistical analyses were performed with RStudio (RStudio, PBC, Boston, MA; desktop v. 1.4.1717), which offers a graphical user interface for R (The R Foundation for Statistical Computing, Vienna, Austria, v. 4.0.3). Median values, percentages of total, and estimated median overall survival were calculated as described in the descriptive statistics section (Table 2). For survival estimation, the survival (v. 3.2-13) and survminer (v. 0.4.9) packages in R were utilized. The Kaplan-Meier method was employed to estimate survival curves. The log-rank test was applied for analyzing differences in survival based on variables such as ALDH1A1 Expression, Age, Sex, pT- and pN-status, and lymph vessel invasion. To dichotomize ALDH1A1 expression and age, the "cutpointr" function from the cutpointr package (v. 1.1.2) was used to determine optimal cut-off values. This function determines the optimal threshold for splitting a continuous variable, such as biomarker expression, to help predict survival outcomes. It assesses various thresholds of the biomarker to find the cutpoint that optimizes a selected metric—typically the sum of sensitivity and specificity—relative to a binary outcome, like survival status (34). This allows for the classification of patients into high-risk and low-risk groups based on their biomarker levels.

Cox Proportional Hazards Models were applied to evaluate the impact of variables such as ALDH1A1 Expression, Age, Sex, T- and N-Classification, Grading, Blood and Lymph Vessel Invasion. For all statistical methods, the p-value for significance was defined as p ≤0.05.

Results

Clinicopathological parameters

In total, 69 patients (34 male (51%); 35 female (49%)) with a mean age of 64 years at the time of surgical resection (range 33 - 83) were included in the study.

In accordance with the UICC-Classification (8th version), 33 patients (48%) were classified as pT1, 18 patients (26%) as pT2, 13 patients (19%) as pT3, and 5 patients (7%) as pT4. The mean tumor size was 8.6 cm with a range from 2.5 - 22 cm. Tumor differentiation was graded as G1 in 7 cases (10%), G2 in 40 cases (58%), and G3 in 22 cases (32%). Lymphadenectomy was performed in 39 cases (56%), with evidence of lymph node metastasis in 14 cases (pN1; 20%). No lymph node metastasis was found in 25 cases (pN0; 36%). Due to the extended inclusion period of the study, Lymphadenectomy was not consistently performed as a standard procedure. Lymph vessel invasion was histologically identified in 20 cases (L1; 29%), blood vessel invasion in 15 (V1; 22%), and perineural sheath invasion in 22 cases (Pn1; 32%). A histologically complete resection (R0) was achieved in 53 patients (77%), and an incomplete resection with residual disease in 16 patients (R1; 23%).

Descriptive statistics: ALDH1A1 expression in tumor and stromal-cells

ALDH1A1 expression in both tumor and stromal cells was assessed for all patients, revealing a skewed distribution. The median expression of ALDH1A1 in tumor cells was 90.53%, with a range of 0.00 to 99.75%. Tumor-associated stromal cells exhibited ALDH1A1 expression ranging from 0.00 to 99.45%, with a median of 70.45%.

In the female population, the median ALDH1A1 expression in tumor cells was 92.56%, with values ranging from 2.03 to 99.66%. The associated stromal cells had a median expression of 77.87%, with a range of 1.42 to 99.46%.

In the male subgroup, the median ALDH1A1 expression in tumor cells was 81.51%, with a range from 0.00 to 99.75%, and 63.34% in tumor-associated stromal cells, with a range from 0.00 to 96.84%.

Patients were dichotomized by a cutoff into high- and low-ALDH1A1 expression groups, as described above. The cutoffs for tumor- and stromal-cell expression of ALDH1A1 were set at 94.92% and 88.45%, respectively.

The Pearson´s Chi-squared test showed a significant correlation of ALDH1A1 Expression within tumor and its surrounding stroma cells (p = < 0.001, Table 1, Figure 3).

 Figure 3

Scatter-Plot of ALDH1A1 Expression in tumor and stromacells of individual patients.

 Table 1

The Pearson´s Chi-squared test showed a significant correlation of ALDH1A1 Expression within tumor and its surrounding stroma cells (p = < 0.001).

Survival Analysis

The estimated mean patient overall survival was 48.26 months (range 2 - 180 months), with a median overall survival of 33 months. At the time of the last follow-up, 58 patients (84%) had died. The remaining 11 patients (16%) were censored.

In the Log-rank Analysis for overall survival and the pathological parameters, significantly shortened overall survival was observed for patients with local lymph node metastasis and lymph vessel invasion (p < 0.0001 each). Similarly, an advanced tumor class (> pT1; p = 0.03), incomplete surgical resection (R1; p = 0.013), and blood vessel invasion (V1; p = 0.048) significantly shortened overall survival. Other clinicopathological parameters did not show a significant impact on overall survival in this study (Sex, Age, Perineural Sheath Invasion (Pn), Tumor Grade).

In both tumor and stromal cells, high ALDH1A1 expression correlated with significantly longer patient overall survival (ALDH1A1 expression in tumor p = 0.0068; ALDH1A1 expression in stroma p = 0.008) (Figure 4 A, B)).

Next, patients were stratified by sex using the same cutoffs. This split showed significantly prolonged overall survival in the female subpopulation for high ALDH1A1 expression in tumor (p = 0.0077) and stromal cells (p = 0.043) (Figure 4 C, D). There were no significant results in the male subpopulation for expression in tumor or stromal cells (p = 0.2; p = 0.13, respectively) (Figure 4 E, F).

Analysis of the hazard ratio using the Cox-regression (Table 2 and Table 3)

Univariate Cox regression model showed prognostic significance for ALDH1A1 expression in both tumor and stromal cells. Low ALDH1A1 expression correlated with a dismal survival (tumor: HR = 2.19; CI [1.22, 3.93]; p = 0.008; stroma: HR = 2.4; CI [1.23, 4.67]; p = 0.01). Further significant prognosticators included T-Classification (pT3: HR = 2.36; CI [1.17, 4.75]; p = 0.016), lymph node involvement (pN1: HR = 3.47; CI [1.66, 7.26]; p < 0.001), perineural sheath invasion (HR = 1.77; CI [1.01, 3.11]; p = 0.046), lymph vessel invasion (HR = 3.05; CI [1.7, 5.49]; p < 0.001), blood vessel invasion (HR = 1.89; CI [1.02, 3.49]; p = 0.042), and incomplete surgical resection (HR = 2.66; CI [1.44, 4.89]; p = 0.002). Tumor-grade, patient age, or sex did not show a significant impact on the hazard ratio.

Due to the co-dependency of ALDH1A1 expression in tumor and stromacells, as shown in Table 1 and Figure 3, multivariable Cox regression models were performed separately for each, encompassing all other univariably significant variables (pT, pN, Pn, L, V, Residual Disease) each yielding significant hazard ratios for ALDH1A1 expression. As in the univariable analysis low ALDH1A1 expression correlated with an increased risk of death (tumor: HR = 1.95; CI [1.04, 3.66]; p = 0.036; stroma: HR = 2.23; CI [1.11, 4.51]; p = 0.025).

In the female subpopulation, low ALDH1A1 in either tumor or stroma correlated with an increased risk of death (tumor: HR = 2.8; CI [1.27, 6.17]; p = 0.01; stroma: HR = 2.36; CI [1.0, 5.55]; p = 0.049). Furthermore T-Classification (pT2: HR = 2.7; CI [1.16, 6.24]; p = 0.021), lymph node involvement (pN1: HR = 4.73; CI [1.65, 13.6]; p = 0.004), lymph vessel invasion (HR = 8.16; CI [2.93, 22.8]; p < 0.001), blood vessel invasion (HR = 3.72; CI [1.46, 9.45]; p = 0.006), and incomplete surgical resection (HR = 3.92; CI [1.65, 9.3]; p = 0.002). Tumor-grade, patient age, and perineural sheath invasion did not show a significant impact on the hazard ratio. ALDH1A1 expression did not show an independently significant impact in the multivariable regression models of the female subpopulation.

The Cox regression of the male subpopulation did not show a significant impact of ALDH1A1 Expression on risk of death, neither in the uni- nor on the multivariable model.

Discussion

Recent advancements in oncological treatments have underscored the importance of biomarkers. These biomarkers are broadly categorized into predictive, such as specific receptors in breast cancer and EGFR in metastatic non-small cell lung cancer (35) and prognostic, which indicate disease progression, recurrence, or mortality (36).

In iCC, patient outcomes are predominantly determined by the tumor stage at diagnosis. Current biomarkers for iCC, like CA19-9, CA 125, and CEA, are limited by their specificity and sensitivity, confining their use mainly to monitoring disease progression rather than offering diagnostic or therapeutic insights (37-39). This highlights the need for more reliable prognostic or predictive biomarkers in iCC clinical practice.

ALDH1A1's prognostic significance varies across different cancers. Ding et al. highlighted a negative prognostic impact associated with high ALDH1A1 expression in cholangiocellular carcinoma, disregarding the anatomical cancer origin (intra- and extrahepatic cholangiocarcinoma). Furthermore their review focused on in vitro studies and not in vivo data / comprising patients outcome (40). In iCC, research linking ALDH1A1 to patient overall survival has been inconsistent, potentially due to methodological variations, including the use of immunohistochemistry on whole slides versus TMAs and manual versus AI-based evaluations (18,30). Additionally, differing etiologies between Asian and Western patients, such as liver fluke infections and chronic hepatitis B and C in Asia versus primary sclerosing cholangitis and metabolic syndrome in the West, might lead to different impacts of ALDH1A1 expression on survival in studies performed (41,42). Furthermore, the heterogeneous nature of iCC and its diverse genetic and environmental influences might contribute to these discrepancies (43). Finally, the dual role of ALDH1A1 in both tumor cells and the tumor microenvironment might lead to complex interactions that are not yet fully understood (44,45).

 Figure 4

Kaplan-Meier survival curves of ALDH1A1 expression in tumor and surrounding stromal cells of the whole cohort (A, B) as well as in the female (C, D) and male (E, F) subgroup.

 Table 2

Descriptive statistics, univariable and multivariable Cox regression of ALDH1A1 expression in iCC. Significant results are highlighted in bold.

 Table 3

Descriptive statistics, univariable and multivariable Cox regression of ALDH1A1 expression in iCC within the female subpopulation. Significant results are highlighted in bold.

Our study utilized a TMA-based approach with AI for objective, user-independent evaluation, minimizing staining variability (46) and reducing interobserver variability. The importance of the tumor microenvironment in cancer progression is increasingly recognized in oncological research (47-53).

Interestingly, ALDH1A1 expression in stromal cells has been largely overlooked. Only a few isolated studies, particularly in breast cancer, have explored its role in the TME and its impact on tumorigenesis.

Our findings reveal that ALDH1A1 overexpression in tumor cells correlates with prolonged patient survival in iCC, contradicting its typical association with higher tumorigenicity (54,55), and cancer stem cells (56). Our data also indicated a significant correlation between ALDH1A1 overexpression in stromal cells and improved patient outcomes, consistent with previous reports in iCCs (29) and other primary liver cancers (27,57-59).

Furthermore, we investigated ALDH1A1's impact on patient outcomes based on gender, observing a significant effect in female patients. Cox regression analysis indicated significant hazard ratios for ALDH1A1 expression in both tumor and stromal cells, in univariable as well as multivariable models. Given that intrahepatic cholangiocellular carcinoma falls under the category of rare diseases, resulting in a naturally low patient count, there is a pressing need for further studies to investigate potential gender-specific biological mechanisms underlying ALDH1A1 expression in iCC.

The immunohistochemical detection of ALDH1A1 is straightforward and cost-effective, suggesting its potential as a reliable prognostic marker in iCC. However, the current lack of effective treatment options for iCC means that even a favorable prognosis does not significantly alter therapeutic strategies. The possibility of ALDH1A1 serving as a predictive marker for targeted therapies remains an area for future exploration (60,61).

Conclusion

ALDH1A1 overexpression in both tumor and stromal cells has been shown to favorably impact overall survival in iCC. However, these results need to be validated in larger patient cohorts. If validated, ALDH1A1 could become a significant prognostic biomarker, aiding future patient management. The study's findings on ALDH1A1, particularly its varying impact based on gender, provide new insights. The favorable prognostic impact of high ALDH1A1 expression in tumor cells aligns with results from hepatocellular carcinoma studies, suggesting a broader relevance across primary liver cancers. This study's methodology, focusing on the tumor microenvironment and employing advanced techniques like AI-supported evaluation, underscores the evolving landscape of oncological research and the potential for new therapeutic strategies in managing devastating conditions like iCC.

Competing Interests

The authors have declared that no competing interest exists.

References

1. Banales JM, Cardinale V, Carpino G, Marzioni M, Andersen JB, Invernizzi P. et al. Expert consensus document: Cholangiocarcinoma: current knowledge and future perspectives consensus statement from the European Network for the Study of Cholangiocarcinoma (ENS-CCA). Nat Rev Gastroenterol Hepatol [Internet]. 2016 May 1 [cited. 2023 Sep 6];13(5):261-80. Available from: https://pubmed.ncbi.nlm.nih.gov/27095655/

2. Ghouri Y, Mian I, Blechacz B. Cancer review: Cholangiocarcinoma. J Carcinog [Internet]. 2015 Jan 1 [cited. 2023 Sep 6];14(1). Available from: https://pubmed.ncbi.nlm.nih.gov/25788866/

3. Lindnér P, Rizell M, Hafström L. The impact of changed strategies for patients with cholangiocarcinoma in this millenium. HPB Surg [Internet]. 2015 [cited 2023 Sep 6]. 2015 Available from: https://pubmed.ncbi.nlm.nih.gov/25788760/

4. Strijker M, Belkouz A, van der Geest LG, van Gulik TM, van Hooft JE, de Meijer VE. et al. Treatment and survival of resected and unresected distal cholangiocarcinoma: a nationwide study. Acta Oncol [Internet]. 2019 Jul 3 [cited. 2023 Sep 6];58(7):1048-55. Available from: https://pubmed.ncbi.nlm.nih.gov/30907207/

5. Spolverato G, Kim Y, Alexandrescu S, Marques HP, Lamelas J, Aldrighetti L. et al. Management and Outcomes of Patients with Recurrent Intrahepatic Cholangiocarcinoma Following Previous Curative-Intent Surgical Resection. Ann Surg Oncol [Internet]. 2016 Jan 1 [cited. 2023 Sep 6];23(1):235-43. Available from: https://pubmed.ncbi.nlm.nih.gov/26059651/

6. Kumar M, Zhao X, Wang XW. Molecular carcinogenesis of hepatocellular carcinoma and intrahepatic cholangiocarcinoma: one step closer to personalized medicine? Cell Biosci [Internet]. 2011 Jan 24 [cited. 2023 Oct 17];1(1). Available from: https://pubmed.ncbi.nlm.nih.gov/21711594/

7. Nakanuma Y, Sato Y, Harada K, Sasaki M, Xu J, Ikeda H. Pathological classification of intrahepatic cholangiocarcinoma based on a new concept. World J Hepatol [Internet]. 2010 [cited. 2023 Oct 17];2(12):419-27. Available from: https://pubmed.ncbi.nlm.nih.gov/21191517/

8. Sithithaworn P, Yongvanit P, Duenngai K, Kiatsopit N, Pairojkul C. Roles of liver fluke infection as risk factor for cholangiocarcinoma. J Hepatobiliary Pancreat Sci [Internet]. 2014 [cited. 2023 Oct 17];21(5):301-8. Available from: https://pubmed.ncbi.nlm.nih.gov/24408775/

9. Palmer WC, Patel T. Are common factors involved in the pathogenesis of primary liver cancers? A meta-analysis of risk factors for intrahepatic cholangiocarcinoma. J Hepatol [Internet]. 2012 Jul [cited. 2023 Oct 17];57(1):69-76. Available from: https://pubmed.ncbi.nlm.nih.gov/22420979/

10. Brandi G, Girolamo S Di, Farioli A, Rosa F De, Curti S, Pinna AD. et al. Asbestos: a hidden player behind the cholangiocarcinoma increase? Findings from a case-control analysis. Cancer Causes Control [Internet]. 2013 May [cited. 2023 Oct 17];24(5):911-8. Available from: https://pubmed.ncbi.nlm.nih.gov/23408245/

11. Marchitti SA, Brocker C, Stagos D, Vasiliou V. Non-P450 aldehyde oxidizing enzymes: the aldehyde dehydrogenase superfamily. Expert Opin Drug Metab Toxicol [Internet]. 2008 Jun [cited. 2023 Mar 21];4(6):697-720. Available from: https://pubmed.ncbi.nlm.nih.gov/18611112/

12. Braun T, Bober E, Singh S, Agarwal DP, Goedde HW. Evidence for a signal peptide at the amino-terminal end of human mitochondrial aldehyde dehydrogenase. FEBS Lett [Internet]. 1987 May 11 [cited. 2023 Mar 21];215(2):233-6. Available from: https://pubmed.ncbi.nlm.nih.gov/3582651/

13. Ginestier C, Hur MH, Charafe-Jauffret E, Monville F, Dutcher J, Brown M. et al. ALDH1 is a marker of normal and malignant human mammary stem cells and a predictor of poor clinical outcome. Cell Stem Cell [Internet]. 2007 Nov 15 [cited. 2023 Mar 21];1(5):555-67. Available from: https://pubmed.ncbi.nlm.nih.gov/18371393/

14. Huang EH, Hynes MJ, Zhang T, Ginestier C, Dontu G, Appelman H. et al. Aldehyde dehydrogenase 1 is a marker for normal and malignant human colonic stem cells (SC) and tracks SC overpopulation during colon tumorigenesis. Cancer Res [Internet]. 2009 Apr 15 [cited. 2023 Mar 21];69(8):3382-9. Available from: https://pubmed.ncbi.nlm.nih.gov/19336570/

15. Patel M, Lu L, Zander DS, Sreerama L, Coco D, Moreb JS. ALDH1A1 and ALDH3A1 expression in lung cancers: correlation with histologic type and potential precursors. Lung Cancer [Internet]. 2008 [cited. 2023 Mar 21];59(3):340-9. Available from: https://pubmed.ncbi.nlm.nih.gov/17920722/

16. Ciccone V, Terzuoli E, Donnini S, Giachetti A, Morbidelli L, Ziche M. Correction to: Stemness marker ALDH1A1 promotes tumor angiogenesis via retinoic acid/HIF-1α/VEGF signalling in MCF-7 breast cancer cells. J Exp Clin Cancer Res [Internet]. 2019 Feb 1 [cited. 2023 Oct 17];38(1). Available from: https://pubmed.ncbi.nlm.nih.gov/30709378/

17. Althobiti M, El Ansari R, Aleskandarany M, Joseph C, Toss MS, Green AR. et al. The prognostic significance of ALDH1A1 expression in early invasive breast cancer. Histopathology [Internet]. 2020 Sep 1 [cited. 2023 Oct 17];77(3):437-48. Available from: https://pubmed.ncbi.nlm.nih.gov/32369651/

18. Shuang ZY, Wu WC, Xu J, Lin G, Liu YC, Lao XM. et al. Transforming growth factor-β1-induced epithelial-mesenchymal transition generates ALDH-positive cells with stem cell properties in cholangiocarcinoma. Cancer Lett [Internet]. 2014 Nov 28 [cited. 2023 Mar 21];354(2):320-8. Available from: https://pubmed.ncbi.nlm.nih.gov/25194504/

19. Landen CN, Goodman B, Katre AA, Steg AD, Nick AM, Stone RL. et al. Targeting aldehyde dehydrogenase cancer stem cells in ovarian cancer. Mol Cancer Ther [Internet]. 2010 Dec [cited. 2023 Oct 17];9(12):3186-99. Available from: https://pubmed.ncbi.nlm.nih.gov/20889728/

20. Tanei T, Morimoto K, Shimazu K, Seung JK, Tanji Y, Taguchi T. et al. Association of breast cancer stem cells identified by aldehyde dehydrogenase 1 expression with resistance to sequential Paclitaxel and epirubicin-based chemotherapy for breast cancers. Clin Cancer Res [Internet]. 2009 Jun 15 [cited. 2023 Oct 17];15(12):4234-41. Available from: https://pubmed.ncbi.nlm.nih.gov/19509181/

21. Cojoc M, Peitzsch C, Kurth I, Trautmann F, Kunz-Schughart LA, Telegeev GD. et al. Aldehyde Dehydrogenase Is Regulated by β-Catenin/TCF and Promotes Radioresistance in Prostate Cancer Progenitor Cells. Cancer Res [Internet]. 2015 Apr 1 [cited. 2023 Oct 17];75(7):1482-94. Available from: https://pubmed.ncbi.nlm.nih.gov/25670168/

22. Kitahara O, Katagiri T, Tsunoda T, Harima Y, Nakamura Y. Classification of sensitivity or resistance of cervical cancers to ionizing radiation according to expression profiles of 62 genes selected by cDNA microarray analysis. Neoplasia [Internet]. 2002 [cited. 2023 Oct 17];4(4):295-303. Available from: https://pubmed.ncbi.nlm.nih.gov/12082545/

23. Penumatsa K, Edassery SL, Barua A, Bradaric MJ, Luborsky JL. Differential expression of aldehyde dehydrogenase 1a1 (ALDH1) in normal ovary and serous ovarian tumors. J Ovarian Res [Internet]. 2010 [cited. 2023 Mar 21];3(1). Available from: https://pubmed.ncbi.nlm.nih.gov/21176222/

24. Huang K, Li LA, Meng YG, You YQ, Fu XY, Song L. Arctigenin Promotes Apoptosis in Ovarian Cancer Cells via the iNOS/NO/STAT3/Survivin Signalling. Basic Clin Pharmacol Toxicol [Internet]. 2014 Dec 1 [cited. 2024 Jan 21];115(6):507-11. Available from: https://onlinelibrary.wiley.com/doi/full/10.1111/bcpt.12270

25. Gao F, Zhou B, Xu JC, Gao X, Li SX, Zhu GC. et al. The role of LGR5 and ALDH1A1 in non-small cell lung cancer: Cancer progression and prognosis. Biochem Biophys Res Commun. 2015Jun26;462(2):91-8

26. Suzuki E, Chiba T, Zen Y, Miyagi S, Tada M, Kanai F. et al. Aldehyde dehydrogenase 1 is associated with recurrence-free survival but not stem cell-like properties in hepatocellular carcinoma. Hepatol Res [Internet]. 2012 Nov 1 [cited 2024 Jan 21];42(11):1100-11. Available from: https://onlinelibrary.wiley.com/doi/full/10.1111/j.1872-034X. 2012 01028.x

27. Tanaka K, Tomita H, Hisamatsu K, Nakashima T, Hatano Y, Sasaki Y. et al. ALDH1A1-overexpressing cells are differentiated cells but not cancer stem or progenitor cells in human hepatocellular carcinoma. Oncotarget [Internet]. 2015 Sep 9 [cited. 2023 Mar 22];6(28):24722. Available from: /pmc/articles/PMC4694791/

28. Kahlert C, Bergmann F, Beck J, Welsch T, Mogler C, Herpel E. et al. Low expression of aldehyde deyhdrogenase 1A1 (ALDH1A1) is a prognostic marker for poor survival in pancreatic cancer. BMC Cancer [Internet]. 2011 Jun 27 [cited. 2024 Jan 21];11:275. Available from: /pmc/articles/PMC3135572/

29. Padthaisong S, Thanee M, Namwat N, Phetcharaburanin J, Klanrit P, Khuntikeo N. et al. Overexpression of a panel of cancer stem cell markers enhances the predictive capability of the progression and recurrence in the early stage cholangiocarcinoma. J Transl Med [Internet]. 2020 Feb 10 [cited. 2023 Mar 21];18(1). Available from: https://pubmed.ncbi.nlm.nih.gov/32039729/

30. Jun Y, Yoshimitsu A, Shu S, Toshiro O, Kosuke O, Hiroaki O. et al. Loss of ARID1A induces a stemness gene ALDH1A1 expression with histone acetylation in the malignant subtype of cholangiocarcinoma. Carcinogenesis [Internet]. 2020 Jul 10 [cited. 2023 Mar 29];41(6):734-42. Available from: https://academic.oup.com/carcin/article/41/6/734/5610211

31. Human Aldehyde Dehydrogenase 1-A1/ALDH1A1 Antibody MAB5869. R&D Systems [Internet]. [cited. 2024 Aug 15]. Available from: https://www.rndsystems.com/products/human-aldehyde-dehydrogenase-1-a1-aldh1a1-antibody-703410_mab5869?gad_source=1&gclid=EAIaIQobChMIuabzwbD2hwMV0ZpoCR0HWAlDEAAYASAAEgKayfD_BwE&gclsrc=aw.ds#product-datasheets

32. Tissue expression of ALDH1A1 - Staining in prostate - The Human Protein Atlas [Internet]. [cited 2024 Aug 15]. Available from: https://www.proteinatlas.org/ENSG00000165092-ALDH1A1/tissue/prostate.

33. Bankhead P, Loughrey MB, Fernández JA, Dombrowski Y, McArt DG, Dunne PD. et al. QuPath: Open source software for digital pathology image analysis. Sci Rep. 2017 7(1)

34. Thiele C, Hirschfeld G. cutpointr: Improved Estimation and Validation of Optimal Cutpoints in R. J Stat Softw [Internet]. 2021 Jun 30 [cited. 2024 Jul 19];98:1-27. Available from: https://www.jstatsoft.org/index.php/jss/article/view/v098i11

35. Clark GM, Zborowski DM, Culbertson JL, Whitehead M, Savoie M, Seymour L. et al. Clinical Utility of Epidermal Growth Factor Receptor Expression for Selecting Patients with Advanced Non-small Cell Lung Cancer for Treatment with Erlotinib. J Thorac Oncol. 2006Oct1;1(8):837-46

36. Ballman K V. Biomarker: Predictive or prognostic? J Clin Oncol. 2015Nov20;33(33):3968-71

37. Macias RIR, Banales JM, Sangro B, Muntané J, Avila MA, Lozano E. et al. The search for novel diagnostic and prognostic biomarkers in cholangiocarcinoma. Biochim Biophys acta Mol basis Dis [Internet]. 2018 Apr 1 [cited. 2023 Apr 6];1864(4 Pt B):1468-77. Available from: https://pubmed.ncbi.nlm.nih.gov/28782657/

38. Rodrigues PM, Vogel A, Arrese M, Balderramo DC, Valle JW, Banales JM. Next-Generation Biomarkers for Cholangiocarcinoma. Cancers (Basel) [Internet]. 2021 Jul 1 [cited. 2023 Apr 6];13(13). Available from: /pmc/articles/PMC8269024/

39. Macias RIR, Kornek M, Rodrigues PM, Paiva NA, Castro RE, Urban S. et al. Diagnostic and prognostic biomarkers in cholangiocarcinoma. Liver Int [Internet]. 2019 May 1 [cited. 2023 Apr 6];39(S1):108-22. Available from: https://onlinelibrary.wiley.com/doi/full/10.1111/liv.14090

40. Ding B, Song Y, Liu S, Peng C, Zhang Y. Mechanisms underlying the changes in acetaldehyde dehydrogenase 1 in cholangiocarcinoma. J Cancer [Internet]. 2023 [cited. 2024 Mar 26];14(17):3203. Available from: /pmc/articles/PMC10622993/

41. Sripa B, Kaewkes S, Sithithaworn P, Mairiang E, Laha T, Smout M. et al. Liver Fluke Induces Cholangiocarcinoma. PLOS Med [Internet]. 2007 [cited. 2024 Aug 4];4(7):e201. Available from: https://journals.plos.org/plosmedicine/article?id=10.1371/journal.pmed.0040201

42. Banales JM, Marin JJG, Lamarca A, Rodrigues PM, Khan SA, Roberts LR. et al. Cholangiocarcinoma 2020: the next horizon in mechanisms and management. Nat Rev Gastroenterol Hepatol [Internet]. 2020 Sep 1 [cited. 2024 Aug 4];17(9):557. Available from: /pmc/articles/PMC7447603/

43. Banales JM, Marin JJG, Lamarca A, Rodrigues PM, Khan SA, Roberts LR. et al. Cholangiocarcinoma 2020: the next horizon in mechanisms and management. Nat Rev Gastroenterol Hepatol [Internet]. 2020 Sep 1 [cited. 2024 Jul 23];17(9):557. Available from: /pmc/articles/PMC7447603/

44. Liu C, Qiang J, Deng Q, Xia J, Deng L, Zhou L. et al. ALDH1A1 Activity in Tumor-Initiating Cells Remodels Myeloid-Derived Suppressor Cells to Promote Breast Cancer Progression. Cancer Res [Internet]. 2021 Dec 1 [cited. 2024 Jul 23];81(23):5919-34. Available from: /cancerres/article/81/23/5919/674828/ALDH1A1-Activity-in-Tumor-Initiating-Cells

45. Gorodetska I, Offermann A, Püschel J, Lukiyanchuk V, Gaete D, Kurzyukova A. et al. ALDH1A1 drives prostate cancer metastases and radioresistance by interplay with AR- and RAR-dependent transcription. Theranostics [Internet]. 2024 [cited. 2024 Jul 23];14(2):714. Available from: /pmc/articles/PMC10758061/

46. Libard S, Cerjan D, Alafuzoff I. Characteristics of the tissue section that influence the staining outcome in immunohistochemistry. Histochem Cell Biol [Internet]. 2019 Jan 29 [cited. 2023 Mar 30];151(1):91-6. Available from: https://link.springer.com/article/10.1007/s00418-018-1742-1

47. Hanahan D, Weinberg RA. Hallmarks of Cancer: The Next Generation. Cell. 2011Mar4;144(5):646-74

48. Tlsty TD, Hein PW. Know thy neighbor: stromal cells can contribute oncogenic signals. Curr Opin Genet Dev. 2001Feb1;11(1):54-9

49. Elenbaas B, Weinberg RA. Heterotypic signaling between epithelial tumor cells and fibroblasts in carcinoma formation. Exp Cell Res [Internet]. 2001 Mar 10 [cited. 2023 Apr 4];264(1):169-84. Available from: https://pubmed.ncbi.nlm.nih.gov/11237532/

50. Mayer S, Milo T, Isaacson A, Halperin C, Miyara S, Stein Y. et al. The tumor microenvironment shows a hierarchy of cell-cell interactions dominated by fibroblasts. Nat Commun 2023 141 [Internet]. 2023 Sep 19 [cited. 2024 Jan 19];14(1):1-17. Available from: https://www.nature.com/articles/s41467-023-41518-w

51. de Visser KE, Joyce JA. The evolving tumor microenvironment: From cancer initiation to metastatic outgrowth. Cancer Cell [Internet]. 2023 Mar 13 [cited. 2024 Jan 19];41(3):374-403. Available from: https://pubmed.ncbi.nlm.nih.gov/36917948/

52. Peltanova B, Raudenska M, Masarik M. Effect of tumor microenvironment on pathogenesis of the head and neck squamous cell carcinoma: a systematic review. Mol Cancer [Internet]. 2019 Mar 30 [cited. 2024 Jan 19];18(1). Available from: https://pubmed.ncbi.nlm.nih.gov/30927923/

53. Goliwas KF, Deshane JS, Elmets CA, Athar M. Moving Immune Therapy Forward Targeting TME. Physiol Rev [Internet]. 2021 [cited. 2024 Jan 19];101(2):417-25. Available from: https://pubmed.ncbi.nlm.nih.gov/32790578/

54. Bednarz-Knoll N, Nastały P, Zaczek A, Stoupiec M, Riethdorf S, Wikman H. et al. Stromal expression of ALDH1 in human breast carcinomas indicates reduced tumor progression. Oncotarget [Internet]. 2015 Sep 9 [cited. 2023 Mar 22];6(29):26789. Available from: /pmc/articles/PMC4694953/

55. Sjostrom M, Hartman L, Honeth G, Grabau D, Malmstrom P, Hegardt C. et al. Stem cell biomarker ALDH1A1 in breast cancer shows an association with prognosis and clinicopathological variables that is highly cut-off dependent. J Clin Pathol [Internet]. 2015 Dec 1 [cited. 2023 Mar 22];68(12):1012-9. Available from: https://pubmed.ncbi.nlm.nih.gov/26175266/

56. Ma YC, Yang JY, Yan LN. Relevant markers of cancer stem cells indicate a poor prognosis in hepatocellular carcinoma patients: A meta-analysis [Internet]. Vol. 25, European Journal of Gastroenterology and Hepatology. Eur J Gastroenterol Hepatol; 2013 [cited. 2023 Oct 20]. p. 1007-16. Available from: https://pubmed.ncbi.nlm.nih.gov/23478672/

57. Suzuki E, Chiba T, Zen Y, Miyagi S, Tada M, Kanai F. et al. Aldehyde dehydrogenase 1 is associated with recurrence-free survival but not stem cell-like properties in hepatocellular carcinoma. Hepatol Res [Internet]. 2012 Nov 1 [cited 2023 Mar 22];42(11):1100-11. Available from: https://onlinelibrary.wiley.com/doi/full/10.1111/j.1872-034X. 2012 01028.x

58. Ma S, Kwok WC, Lee TKW, Kwan HT, Wo JYH, Zheng BJ. et al. Aldehyde dehydrogenase discriminates the CD133 liver cancer stem cell populations. Mol Cancer Res [Internet]. 2008 Jul 1 [cited. 2023 Mar 22];6(7):1146-53. Available from: https://pubmed.ncbi.nlm.nih.gov/18644979/

59. Yang CK, Wang XK, Liao XW, Han CY, Yu TD, Qin W. et al. Aldehyde dehydrogenase 1 (ALDH1) isoform expression and potential clinical implications in hepatocellular carcinoma. PLoS One [Internet]. 2017 Aug 1 [cited. 2023 Mar 22];12(8). Available from: /pmc/articles/PMC5549701/

60. Muralikrishnan V, Fang F, Given TC, Podicheti R, Chtcherbinine M, Metcalfe TX. et al. A Novel ALDH1A1 Inhibitor Blocks Platinum-Induced Senescence and Stemness in Ovarian Cancer. Cancers 2022, Vol 14, Page 3437 [Internet]. 2022 Jul 15 [cited. 2023 Mar 29];14(14):3437. Available from: https://www.mdpi.com/2072-6694/14/14/3437/htm

61. Kozovska Z, Patsalias A, Bajzik V, Durinikova E, Demkova L, Jargasova S. et al. ALDH1A inhibition sensitizes colon cancer cells to chemotherapy. BMC Cancer [Internet]. 2018 Jun 15 [cited. 2024 Mar 26];18(1):1-11. Available from: https://bmccancer.biomedcentral.com/articles/10.1186/s12885-018-4572-6

Author contact

Corresponding author: Dr. Sylvia Timme, Institute for Surgical Pathology, University Medical Center Freiburg, Breisacher Straße 115A, 79106 Freiburg, Germany. Tel.: +49(0)761-270-80060; E-mail: sylvia.timmede.

Received 2024-6-21
Accepted 2024-9-21
Published 2025-1-1
